Laminadora ecoflex 1350 mm

FOR THE PRODUCTION OF DUBLE LAMINATES SOLVENT AND SOLVENTLESS LAMINATOR FOR WIDEST RANGE OF SUBSTRATES

· wide range of flexible packaging laminates can be laminated and cold seal coated

· Web width: min. 675 mm/ 1350 mm – maxim.

· Max mechanical Speed: 300 m/min….working 200 m/min

UNWINDER REEL STANDS 1+2 Roll diameter 1000 mm / weight 800 kg + 2x edge guide

Internal core diameter 70/76 mm

REWINDER REEL STAND Roll diameter 1000 mm / weight 800 kg

. Internal core diameter 152 mm

· Lamination: type solvent and solventless 2 coating trolleys + „so cold“ : carriage system

· A wide range of flexible packaging laminates can be produced on the COMBI schiavi series

· 2 Corona treatments MERO, BOBST REGISTER, 3 cooling units included

· MIXTURE of gluer for solvent and for solventless, + additional COLDSEAL for spot coating

· Materials to be laminating including BOPP, PETP, PE LDPE, LLPE, OPA, Nylon cast, films, PP, ALU foil and paper

· Laminated materials BOPP, PETP, PE LDPE, LLDPE, PVC,EVOH, OPA, Nylon cast, films, PP, ALU foil and paper

· Up to 550 micron

System of drying : combi dryer OIL with ELECTRO, LEL (Lower explosive Limit)

· more than 70 sleeves will be deliver with the machine.
